System Board Information 329
PowerEdge M610x Expansion-Card Riser
Figure 7-9. PowerEdge M610x Expansion-Card Riser Connectors
6 MEZZ1_FAB_C1 Mezzanine card connector - Fabric C
7 Data 3 Data cable connector 3
Connector Description
1 Data 1 Data cable connector 1
2 Data 2 Data cable connector 2
Table 7-15. PowerEdge M610x Midplane Interface Card Connectors
(continued)
Connector Description
1
2
4
6
3
5
7
