318 System Board Information
PowerEdge M905 System Board
Figure 7-2. PowerEdge M905 System Board Connectors
Table 7-9. PowerEdge M905 System Board Connectors
Connector Description
1 MEZZ4_FAB_B Mezzanine card connector 4 Fabric B
2 - SD card connector
3- System board retention pin
4 B1 – B8 Memory modules B1 – B8
5 CPU2 Processor 2 socket
6 D1 – D4 Memory modules D1 – D4
7 CPU4 Processor 4 socket
1
20
2
3
4
5
6
7
8
10
9
12
13
17
15
16
19
18
11
14
