334 System Board Information
Disabling a Forgotten Password
The blade's software security features include a system password and a setup
password, which are discussed in detail in "Using the System Setup Program
and UEFI Boot Manager" on page 127.
The password jumper enables these
password features or disables them, and clears any password(s) currently in use.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1
Remove the blade. See "Removing a Blade" on page 145.
2
Open the blade. See "Opening the Blade" on page 149.
3
If you are changing the jumper setting on a PowerEdge M905 or M805
blade, remove the system board to gain access to the jumpers. See
"Removing the System Board" on page 255.
4
Relocate the jumper plug to disable the password feature.
See "System Board Connectors" on page 316 to locate the password jumper
on the blade board.
5
If you are changing the jumper setting on a PowerEdge M905 or M805
blade, reinstall the system board. See "Installing the System Board" on
page 258.
13 SASBKPLN Hard-drive backplane connector
14 J_STORAGE Storage controller card connector
15 CPU2 Processor 2 socket
16 J_VIDEO Video controller card connector
17 PWRD_EN,
NVRAM_CLR
Configuration jumpers
18 TOE_KEY Hardware key socket for enabling the integrated NIC
TOE/iSCSI feature
Table 7-17. PowerEdge M600 System Board Connectors
(continued)
Connector Description
