Ducati Hypermotard User Manual

Light control
Headlight control
This function allows you to reduce current
consumption from the battery by automatically
managing headlight switching-off.
At Key-On, the high beam and low beam lights are
off. As soon as engine is started, low beams will be
automatically turned on; from now on, "standard"
operation will be active, i.e. whenever button (3) is
pressed, it will be possible to switch from low beams
to high beams with button (3) in position (V) or
"FLASH" with button (3) in position (O). If engine is not
started upon Key-On, lights can nevertheless be
activated by pressing LH high/low beam switch:
button (3) in position (V).
When button is pressed the "first" time, low beams
will be turned on; from now on this button can be
used to turn high beams on or off: if engine is not
started within 60 seconds, low and high beams will
be turned Off.
3
O
V
Fig 68
If the headlight was turned on before starting the
engine with the procedure described above, the
headlight turns off automatically when starting the
vehicle and will turn on again when the engine has
been completely started.
121

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
