Ducati Hypermotard User Manual

Right-hand switch
1) Red ON/OFF switch.
2) Black ENGINE START button.
The switch (1) has three positions:
A) center: RUN OFF. In this position, the engine
cannot be started and all electronic devices are off.
B) pushed down: ON/OFF. In this position, the
system can be turned on (Key-On) and off (Key-Off).
C) pushed up: RUN ON. The engine can only be
started in this position, pushing the black button (2).
2
1
Fig 92
A
B
2
1
C
Fig 93
149

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
