Ducati Hypermotard User Manual

Starting the motorcycle
Attention
Before starting the engine, become familiar
with the controls you will need to use when riding ().
Attention
Never start or run the engine indoors. Exhaust
gases are poisonous and may lead to loss of
consciousness or even death within a short time.
Move the ignition switch to (1, Fig 117). Make sure
that both the green light N and the red light on
the instrument panel are on.
Important
The oil pressure light should go out a few
seconds after the engine has started.
1
Fig 117
Fig 118
169

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
