Ducati Hypermotard User Manual

Instrument Panel (Dashboard)
Instrument panel
1) LCD Dot-Matrix.
2
) REV COUNTER (rpm).
Indicates engine revs per minute.
3) NEUTRAL LIGHT N (GREEN).
Comes on when in neutral position.
4) HIGH BEAM LIGHT
(BLUE).
Turns on to indicate that the high beam lights are on.
5) ENGINE OIL PRESSURE LIGHT (RED).
Comes on when engine oil pressure is too low. It
must turn on at Key-On, but must turn off a few
seconds after the engine has started. May come on
briefly when the engine is hot, but should go off as
the engine revs up.
1
2
7
59 6 47 8 3 10
Fig 9
Important
If ENGINE OIL light stays on, stop the engine or
it may suffer severe damage.
30

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
