Ducati Hypermotard User Manual

Clutch lever
Lever (1) disengages the clutch. When the clutch
lever (1) is operated, drive from the engine to the
gearbox and the drive wheel is disengaged. Using the
clutch properly is essential to smooth riding,
especially when moving off.
Important
Using the clutch properly will avoid damage to
transmission parts and spare the engine.
Note
The engine can be started with the side stand
down and the gearbox in neutral. If starting with a
gear engaged, pull in the clutch lever (in this case the
side stand must be up).
1
Fig 88
146

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
