Ducati Hypermotard User Manual

Helmet cable
Remove seat as described in paragraph "Seat Lock
page 158".
Remove cable (1) from seat.
Pass the cable (1) through the helmet and insert the
ends of the cable in the frame pin (2).
Leave the helmet hanging and refit the seat to hold it
in place.
Attention
This device protects the helmet against theft
when the motorcycle is parked. Do not leave the
helmet attached when riding the motorcycle; it could
interfere with your movements and cause loss of
control of the motorcycle.
1
Fig 108
2
Fig 109
160

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
