Ducati Hypermotard User Manual

Seat lock
Opening
Insert the key (1) into the lock, turn it clockwise and
simultaneously apply downward pressure in the area
of the bolt to release the pin.
Pull the seat (2) backwards to release it from the front
catches.
Closing
Make sure all parts are correctly arranged and
secured in the underseat compartment.
Insert the front ends (A) of the seat base under the
seats (B) on the tank.
2
1
Fig 104
2
A
B
Fig 105
158

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
