Ducati Hypermotard User Manual

Replace the headlight bulbs
Important
Have the bulbs replaced at a Ducati Dealer or
authorized Service Center.
Attention
The headlight might fog up if the vehicle is used
under the rain or after washing. Switch headlight on
for a short time to dry up any condensate.
Before replacing a burnt-out bulb, make sure that the
new one matches the voltage and wattage
specifications in paragraph "Electric System" page
217. Always check that the bulb functions before
reassembling removed parts.
Loosen the screws (1). Slightly raise the headlight
support.
1
Fig 137
Fig 138
189

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
