Ducati Hypermotard User Manual

Left-hand switch
1)
dip switch, two-position light selector switch:
position
= low beam on (A);
position = high beam on (B);
Button = high-beam flasher (FLASH) and
instrument panel control (C).
2) Button = three-position turn indicator:
central position = off;
position = left turn;
position = right turn.
To cancel turn indicators, push in once switch
returns to central position.
3) Button = warning horn.
4)
Instrument panel control button "
";
5)
Instrument panel control button "
";
1
B
C
A
Fig 86
3 5
2
1 4
Fig 87
145

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
