Ducati Hypermotard User Manual

Main maintenance operations
Check and top up the coolant level
Check the coolant level in the expansion reservoir on
the right-hand side of the headstock. Steer the
handlebar completely to the left and check that the
level is between the MIN and MAX marks on the side
of the expansion reservoir. Top up if the level is below
the MIN mark. Unscrew the filler plug (1) and add ENI
Agip Permanent Spezial antifreeze (do not dilute, use
pure), until reaching the MAX level. Refit the plug (1).
This type of mixture ensures the best operating
conditions (the coolant starts to freeze at -4 °F/-20 °C).
1
MAX
MIN
Fig 126
Cooling circuit capacity: 0.61 gal (2.3 cu. dm - liters).
Attention
Make sure the engine is cold before proceeding.
A warm engine could provoke the ejection of coolant
or hot vapor resulting in serious burns.
178

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
