Ducati Hypermotard User Manual

Tank filler plug
Opening
Insert the key into the lock.
Turn the key clockwise 1/4 turn to unlock.
Unscrew the plug (1).
Closing
Tighten the plug (1) with the key inserted and push it
down into its seat.
Turn the key counterclockwise to the initial position
and remove it.
Note
The plug can only be closed with the key in.
Attention
Always make sure you have properly refitted
and closed the plug after refueling.
Fig 102
1
Fig 103
157

Ducati Hypermotard Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis frame
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Torque	71 lb-ft (96 Nm) @ 7, 250 rpm
Front Brake	2 x 320mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245mm disc, 2-piston caliper
