5-20 Disassembly, Assembly, and Adjustment Rev. A
Confidential
Main Assembly 5
Carriage sub assembly
1. Fit the belt over the carriage motor sub assembly gear and the tension plate gear.
Carriage
Belt
Tension plate
gear
Carriage motor
sub assembly gear
sub assembly
