Epson TM-U200 Series Technical Manual

Rev. A Disassembly, Assembly, and Adjustment 5-47
TM-U200 Series (Type A/AM) Technical Manual
Confidential
Main Assembly 8 (Case Unit)
Paper roll receive rollers, upper case, guide roller, and switch panel assemblies
1. The lead wires of the auto-cutter assembly should be arranged as shown in the second part
of the illustration below.
2. Apply G-31 to both of the paper roll receive rollers.
3. Attach the paper roll receive rollers to the lower case.
4. While holding the auto-cutter as shown in the illustration, attach the upper case to the lower
case and secure it with the screws.
5. Apply G-31 to both ends of the guide roller.
6. Attach the guide roller to the upper case.
