Epson TM-U200 Series Technical Manual

Rev. A Mechanism Configuration and Operating Principles 2-5
TM-U200 Series (Type A/AM)Technical Manual
Confidential
Paper Feed Mechanism Unit
The paper feed mechanism unit consists of the parts shown in the figure below. Paper feeding is
performed by driving the paper feed motor (stepping motor).
Figure 2-6 Paper feed mechanism unit
Paper hold
spring
Paper hold roller
Paper hold
roller shaft
Paper feed
roller assembly
Upper paper guide
Paper feed
frame assembly
Paper feed
reduction gear
Paper feed motor
