2-2 Mechanism Configuration and Operating Principles Rev. A
Confidential
Print mechanism unit
The print mechanism unit consists of the parts shown in the figure below.
Figure 2-2 Print mechanism unit
Paper feed
frame assembly
Belt
Print head unit
Belt tension
pulley
Carriage
guide shaft
Carriage shaft
Carriage motor
assembly
Print head FPC
Carriage sub
assembly
