Rev. A Disassembly, Assembly, and Adjustment 5-31
TM-U200 Series (Type A/AM) Technical Manual
Confidential
Main Assembly 15
Ribbon frame earth plate
1. Put the ribbon frame earth plate in the carriage guide shaft.
Ribbon frame earth plate
Carriage guide shaft
