1-4 Features and General Specifications Rev. A
Confidential
Character Specifications
Character sets: Alphanumeric: 95
International: 32
Graphics: 128 x 8 pages
Kanji: JIS Level 1, Level 2 (JIS X0208-1990) (Type AM only)
Character structure: 7 x 9 with 400 half-dot positions per line
9 x 9 with 400 half-dot positions per line
16 x 16 with 400 half-dot positions per line (Type AM only)
Figure 1-3 Character size (7 x 9 font example)
3.1 mm
(0.122")
2.4 mm
(0.094")
1.24 mm (0.049")
1.59 mm (0.063")
0.159 mm (0.006")
0.353 mm
(0.014")
