Essilor Delta 2 Classic User Manual

USER MANUAL > SET THE EDGING SYSTEM
112 Delta 2 - Edging system > v2 - 08.16
2.
3.
4.
1.
2.
Datum mode (½ PD + Datum Height)
The wearer's pupillary height is calculated in relation to the point of intersection with the frame.
ΔY mode (½ PD + ΔY)
ΔY: this value corresponds to the difference inheight between the boxing center of the shape and the pupillary center of the
wearer.
ΔX + ΔY mode
ΔX: this value corresponds tothe horizontal difference between the boxing center of the shape and the pupillary center of the
wearer.
ΔY: this value corresponds to the difference inheight between the boxing center of the shape and the pupillary center of the
wearer.
Once the modification is made, press to return to the work screen.
c. Action bar
This menu enables you to customize the action bar according to your requirements. You can:
enable default options so that they are displayed first in the job options
disable options you do not require so they are no longer displayed in the job options.
To reach the customization menu of the action bar from your working screen, select > > > .
The following screen is displayed:
Type of tracing
Right eye monocular
Left eye monocular
Monocular right eye only
Monocular right eye only
Frame type
Metal frame

Essilor Delta 2 Classic Specifications

General

Brand	Essilor
Model	Delta 2 Classic
Category	Edger
Language	English
