4
3
2
1
the settings of each drilling point in the model
the Y coordinates of each drilling point in relation to the boxing center of the model shape
the distance between the reference drilling point and the edge of the lens
the D-dimension (in mm) you have entered for the tracing
the difference (in mm) between the two reference drilling points on the nasal side (right lens and left
lens)
Once the model has been imported, you can move the drilling points if you wish. For more information, consult the section
.Preparing a drilling job > configuring a drilling point (p.75)
b. Saving a model
This function makes it possible to memorize a shape and its drilling points in a new job with a new ID whilst saving the original job.
Saving a model enables you to save in a new job:
the traced shape
the value of the D-dimension
the drilling point settings
the drilling point heights in relation to the boxing center of the shape (Y coordinates)
the distance from reference drilling points with regard to the edge of the lens (other drilling points, in relation to the reference
drilling point)
Press to save the job and its drilling points.
You can also give it a different ID.
Enter a reference for your model.
Press on to confirm.
Press to return to the centering screen.
You can go back to the previous job via the shape management screen if it has an ID.
The drilling points are positioned keeping:>
Two values are displayed under the work area>
The job-creation alphanumeric keypad is displayed.>
A new ID is allocated (first free slot in the selected list).>
The model is saved in a new job.>
The new job with the new ID is displayed on the drilling screen.>
