e. Modifying a point in the groove curve
Once you have configured the desired type of customized groove, you can complete your customization by moving the groove curve
towards the front or rear surface of the lens so it takes on its shape.
Press from the customized groove finish screen.
Press to select modification of a point in the groove curve.
Using the cursor, select the point on the curve that you want to move or click directly on the screen.
Use the buttons and to move the point on the selected curve.
Press to move it towards the front surface of the lens.
Press to move it towards the rear surface of the lens.
The curve cannot be moved more than the minimum distance between the front and rear surfaces observed on the
groove before the modification.
Close the door.
Press .
Press to go back to the customized bevel finish screen.
f. Displacement of the groove curve
The displacement of the groove curve enables you to move the groove without modifying its curve or perimeter.
Press from the customized groove finish screen.
Press to select the displacement of the curve.
Use the and buttons to displace the curve.
Press to displace it towards the front surface of the lens.
Press to displace it towards the rear surface of the lens.
Close the door.
Press .
Press to release the lens.
If necessary, retouch the lens.
Otherwise, start edging the second lens. Select the lens directly on the screen, on the left or right of the work area.
You will access the trajectory modification screen.>
The position of the groove as well as the distances between the center of the groove and the front & rear surfaces of the
lens are displayed in the zoom window.
>
For the second lens, the customized groove icon is pre-selected and the trajectory modification icon is displayed.>
You will access the trajectory modification screen.>
The position of the groove as well as the distances between the center of the groove and the front & rear surfaces of the
lens are displayed in the zoom window.
>
The edging cycle starts.>
When the edging cycle is finished, the retouch screen is displayed.>
