Feasa 10-F User Manual

FEASA LED ANALYSER
FUNCTIONAL VERSION
Specifications
Part Number(s) Feasa 20-F Standard LED Analyser with 20 Fibers
Feasa 10-F Standard LED Analyser with 10 Fibers
Feasa 6-F Standard LED Analyser with 6 Fibers
Feasa 5-F Standard LED Analyser with 5 Fibers
Feasa 3-F Standard LED Analyser with 3 Fibers
Feasa 2-F Standard LED Analyser with 2 Fibers
Feasa 20-FB High Brightness LED Analyser with 20 Fibers
Feasa 10-FB High Brightness LED Analyser with 10 Fibers
Feasa 6-FB High Brightness LED Analyser with 6 Fibers
Feasa 5-FB High Brightness LED Analyser with 5 Fibers
Feasa 3-FB High Brightness LED Analyser with 3 Fibers
Feasa 2-FB High Brightness LED Analyser with 2 Fibers
Feasa 20-LT Life Tester LED Analyser with 20 Glass Fibers
Feasa 10-LT Life Tester LED Analyser with 10 Glass Fibers
Feasa 5-LT Life Tester LED Analyser with 5 Glass Fibers
Feasa 3-LT Life Tester LED Analyser with 3 Glass Fibers
Physical- F, -FB Dimensions 145mm x 54mm x 39*mm (L x W x H)
Dimensions 104mm x 54mm x 39*mm (L x W x H)
* does NOT include Fiber bend Radius
Plastic Fiber Length 0.6m
Plastic Fiber Diameter 1.0mm
Fiber Core Diameter 0.5mm
Fiber Bend Radius 15mm
Plastic Fiber Temperature Range -40
0
C to +70
0
C
Number of Fibers 2, 3, 5, 6, 10, 20
Led Analyser Operating Temperature Range 0
0
C to +50
0
C
Physical – LT Dimensions 145mm x 54mm x 39*mm (L x W x H)
Dimensions 104mm x 54mm x 39*mm (L x W x H)
* does NOT include Glass Fiber bend Radius
Glass Fiber Length 1.0m
Glass Fiber Diameter 1.1mm
Glass Fiber Core Diameter 0.6mm
Fiber Bend Radius 50mm
Glass Fiber Temperature Range -65
0
C to +125
0
C
Number of Fibers 3, 5, 10, 20
Led Analyser Operating Temperature Range 0
0
C to +50
0
C
Electrical Supply Voltage 5.0V +/- 0.5V
Supply Current 200 mA max in Stand Alone Mode
Supply Current 220 mA max in Daisy Chain Mode
USB 2.0 Interface, Serial RS232 Interface
Output Data Format RGB, HSI, XY, UV, Wavelength, CCT & Intensity
Optical Red Peak Efficiency Wavelength 615 nm
Green Peak Efficiency Wavelength 540 nm
Blue Peak Efficiency Wavelength 465 nm
Total Operating Wavelength Range 450 nm to 650 nm
130
