Feasa 10-F User Manual

FEASA LED ANALYSER
FUNCTIONAL VERSION
Sequence Capture Mode
Set/Put SequenceStartDelay### - Set delay in ms before
sequencecapture starts
Transmit Receive
putsequencestartdelay###
setsequencestartdelay###
OK
OK
Where:
### represents the delay in milliseconds before executing a capturesequence and is in
the range 001-999ms.
Description
This command is used to set a delay in milliseconds before the capturesequence starts. This
can be useful when using the external trigger mode.
PutSequencestartdelay### commands are stored in RAM memory while
SetSequenceStartDelay### commands are stored in Flash memory.
Example:
The PC transmits setsequencestartdelay100 or putsequencestartdelay100 to the LED
Analyser to instruct it to wait 100ms before starting the capturesequence. The LED Analyser
will return a string OK to the PC.
putsequencestartdelay100
OK
To determine the delay in milliseconds before the sequence capture is initiated use the
command getsequencestartdelay It will return an time in the range 000 - 999ms
getsequencestartdelay
123 ms (Delay before Sequence Capture is 123ms)
Back to Index
84
