6-18
[ 3 ] AC reactors (ACRs)
Use an ACR when the converter part of the inverter should supply very stable DC power, for example, in
DC link bus operation (shared PN operation). Generally, ACRs are used for correction of voltage
waveform and power factor or for power supply normalization, but not for suppressing harmonic
components in the power lines. For suppressing harmonic components, use a DCR.
An ACR should be also used when the power source is extremely unstable; for example, when the power
source involves an extremely large interphase voltage unbalance.
Figure 6.10 External View of AC Reactor (ACR) and Connection Example
Table 6.11 AC Reactor (ACR)
Reactance (m:/phase)
50 Hz 60 Hz
1/8
FRNF12C1-2U
2.5
1/4
FRNF25C1-2U
ACR2-0.4A 3 917 1100 5
1/2
FRNF50C1-2U
10
1
FRN001C1-2U
ACR2-0.75A 5 493 592 12
2
FRN002C1-2U
ACR2-1.5A 8 295 354 14
3
FRN003C1-2U
ACR2-2.2A 11 213 256 16
5
FRN005C1-2U
ACR2-3.7A 17 218 153 23
1/2
FRNF50C1-4U
5
1
FRN001C1-4U
10
2
FRN002C1-4U
ACR4-1.5A 3.7 1160 1390 11
3
FRN003C1-4U
ACR4-2.2A 5.5 851 1020 14
5
FRN005C1-4U
ACR4-3.7A 9 512 615 17
1/8
FRNF12C1-7U
5
1/4
FRNF25C1-7U
10
1/2
FRNF50C1-7U
ACR2-0.75A 5 493 592 12
1
FRN001C1-7U
ACR2-1.5A 8 295 354 14
2
FRN002C1-7U
ACR2-2.2A 11 213 256 16
3
FRN003C1-7U
ACR2-3.7A 17 218 262 23
Applicable
motor
rating
(HP)
ACR2-0.4A 3 917 1100
Inverter type
Type
AC reactor (ACR)
Rated current
(A)
Power
supply
voltage
Three-
phase
230 V
Three-
phase
460 V
Single-
phase
230 V
Generated loss
(W)
ACR4-0.75A 2.5 1920 2300
Note 1: Generated losses listed in the above table are approximate values that are calculated according to the following
conditions:
- The power source is 3-phase 230 V/460 V 50 Hz with 0% interphase voltage unbalance ratio.
- The power source capacity uses the larger of either 500 kVA or 10 times the rated capacity of the inverter.
- The motor is a 4-pole standard model at full load (100%).
Note 2: A box (
) in the above table replaces S or E depending on enclosure.
