8.4 Terminal Specifications
8-25
Chap. 8 SPECIFICATIONS
8.4.3.2 Control circuit terminal
The diagram and table below show the control circuit terminal arrangement, screw sizes, and tightening
torque. They are the same in all FRENIC-Mini models.
Screw size: M 2
Screw size: M 2.5
CM
X1 X2 X3
CM FWD REV
FM
30B 30C
Y1
11
Y1E
Screw size Tightening torque
M 2.0 1.6 lb-in (0.2 N·m)
M 2.5 3.2 lb-in (0.4 N·m)
Terminal
symbol
Screwdriver
Allowable wire
size
Bared wire
length
Stick terminal
(see the table below)
Opening dimension in
the control terminals
[30A], [30B],
[30C]
Phillips screwdriver
(JIS standard)
No. 1 screw tip
AWG22 to AWG18
(0.34 to 0.75 mm
2
)
0.24 to 0.31
inch
(6 to 8 mm)
0.11 (W) x 0.7 (H) inch
(2.7 (W) x 1.8 (H) mm)
Other than
those above
Phillips screwdriver for
precision machine
(JCIS standard)
No. 0 screw tip
AWG24 to AWG18
(0.25 to 0.75 mm
2
)
0.20 to 0.28
inch
(5 to 7 mm)
0.07 (W) x 0.06 (H) inch
(1.7 (W) x 1.6 (H) mm)
Recommended stick terminal
Manufacturing company: WAGO Company of Japan., Ltd.
Type (216-)
w/ isolation collar w/o isolation collar
Screw size Wire size
Short type Long type Short type Long type
AWG24 (0.25 mm
2
) 321 301 151 131
AWG22 (0.34 mm
2
) 322 302 152 132
AWG20 (0.50 mm
2
) 221 201 121 101
M 2
M 2.5
AWG18 (0.75 mm
2
) 222 202 122 102
The recommended crimping tool is Name: Variocrimp 4, Model No.: 206-204
