Chapter 9

FUNCTION CODES

This chapter contains overview lists of seven groups of function codes available for the FRENIC-Mini series of

inverters and details of each function code.

Contents

9.1 Function Code Tables.................................................................................................................................. 9-1

9.2 Details of Function Codes......................................................................................................................... 9-12

9.2.1 F codes (Fundamental functions) ...................................................................................................... 9-12

9.2.2 E codes (Extension terminal functions)............................................................................................. 9-33

9.2.3 C codes (Control functions of frequency) ......................................................................................... 9-46

9.2.4 P codes (Motor parameters) .............................................................................................................. 9-49

9.2.5 H codes (High performance functions) ............................................................................................. 9-51

9.2.6 J codes (Application functions)......................................................................................................... 9-64

9.2.7 y codes (Link functions).................................................................................................................... 9-70
