9.2 Details of Function Codes
9-49
Chap. 9 FUNCTION CODES
9.2.4 P codes (Motor parameters)
P02 Motor Parameter (Rated capacity)
Sets the nominal rated capacity that is denoted on the rating nameplate of the motor.
Data for P02 If the nominal rated capacity is:
0.01 to 10.00
0.01 to 10.00 kW
when function code P99 is set to 0, 3 or 4.
0.01 to 10.00
0.01 to 10.00 HP
when function code P99 is set to 1.
P03 Motor Parameter (Rated current)
Sets the nominal rated current that is printed on the rating nameplate of the motor.
- Data setting range: 0.00 to 99.99 (Amp.)
P09 Motor Parameter (Slip compensation gain)
Sets the gain to compensate for the motor slip frequency.
- Data setting range: 0.0 to 200.0 (%)
Compensation gains for the rated slip frequencies listed in the following table are ones for Fuji
standard motors.
Typical rated slip frequencies for 100%
Rated capacity
(HP)
Fuji standard
8-series motors
(Hz)
Typical motors
rated in HP (Hz)
Fuji standard
6-series motors
(Hz)
Other motors
(Hz)
0.1 1.77 2.50 1.77 1.77
1/8 1.77 2.50 1.77 1.77
1/4 2.33 2.50 2.33 2.33
1/2 2.40 2.50 2.40 2.40
1 2.33 2.50 2.33 2.33
2 2.00 2.50 2.00 2.00
3 1.80 1.77 1.80 1.80
5 1.93 1.50 1.93 1.93
The 230 V and 460 V of motors share the same data listed above.
To compensate slip of a motor correctly, the rated voltage (at base frequency) (F05)
and P codes (Motor parameters) should be also set consistently.
