App. G Replacement Information
A-25
App.
App.G Replacement Information
When replacing Fuji conventional inverter series (FVR-C9S, FVR-C11S) with the FRENIC-Mini series,
refer to the replacement information given in this section.
G.1 External dimensions comparison tables
Below is a guide that helps in using the comparison tables on the following pages.
- Mounting area
/Mini (%)
Allows comparing the mounting area required for the FRENIC-Mini series
with that for the conventional inverter series in percentage, assuming the
area for the FRENIC-Mini series to be 100%. If this value is greater than
100%, it means that the mounting area required for the FRENIC-Mini series
is smaller than that of other series.
- Volume/Mini (%) Allows comparing the volume of the FRENIC-Mini series with that of the
conventional inverter series in percentage, assuming the volume of the
FRENIC-Mini series to be 100%. If this value is greater than 100%, it means
that the volume of the FRENIC-Mini is smaller than that of other series.
- In the FRENIC-Mini columns, dimensions in hatched boxes ( ) denote that they are smaller than
those of FVR-C9S and FVR-C11S series.
- In the FVR-C11S and FVR-C9S columns, underlined and bolded dimensions denote that they are
smaller than those of the FRENIC-Mini series.
