3.3 Programming Mode
3-9
Chap. 3 OPERATION USING THE KEYPAD
Limiting menus to be displayed
The menu-driven system has a limiter function (specified by function code E52) that limits menus to be
displayed for the purpose of simple operation. The factory default is to display Menu #1 "Data setting"
only, allowing no switching to any other menu.
Function Code E52 – Keypad (Mode Selection)
Function code data (E52) Menus selectable
0: Function code data setting mode Menu #1 "Data setting" (factory default)
1: Function code data check mode Menu #2 "Data checking"
2: Full-menu mode Menu #1 through #6 (#7*)
* Menu #7 appears only when the remote keypad (option) is set up for use.
If the full-menu mode is selected, pressing the / keys will cycle through menus. With
the key, you may select the desired menu. Once all of the menus have been cycled
through, the display will return to the first menu.
3.3.1 Setting the function codes--"Data Setting"
Menu #1 "Data setting" in Programming mode allows you to set function codes for making the inverter
functions match your needs.
The table below lists the function codes available in the FRENIC-Mini. The function codes are
displayed on the LED monitor on the keypad as shown below.
Table 3.4 List of FRENIC-Mini Function Codes
Function code group Function code Function Description
F codes
(Fundamental functions)
F00 to F51 Basic functions To be used for basic motor running.
E codes
(Extension terminal
functions)
E01 to E99 Terminal
functions
To be used to select the functions of
the control circuit terminals.
To be used to set functions related to
the LED monitor display.
C codes
(Control functions of
frequency)
C01 to C52 Control functions To be used to set application
functions related to frequency
settings.
P codes
(Motor parameters)
P02 to P99 Motor parameters To be used to set specific parameters
for the motor capacity, etc.
H codes
(High performance
functions)
H03 to H98 High level
functions
To be used for high added value
functions and complicated control,
etc.
J codes
(Application functions)
J01 to J06 Application
functions
To be used for PID control.
y codes
(Link functions)
y01 to y99 Link functions To be used for communications.
Refer to Chapter 9 "FUNCTION CODES" for details on the function codes.
