1.3 Connecting Interface Cable 19
1.3 Connecting Interface Cable
Select an interface cable and connect it to the printer.
Important
• Connect the USB cable only after the print driver has been installed on the computer.
1. Connect the interface cable to the interface
connector on the back of the printer. For a
parallel cable, fasten the wire clip on both
sides to secure it after it has been inserted
into the connector.
2. Connect the other end of the cable to the interface connector on the computer.
1.4 Connecting the Power Cord
When connecting the power cord, note the warning and caution items stated in “For Power
& Earth Connection” (P. 10).
1. Connect the power cord to the power cord
connector on the back of the printer.
2. Connect the other end of the power cord to
the power outlet.
Note
• Do not connect the power cord of the printer to the
power outlet of the computer.
To Next Page
