Chapter 2 Troubleshooting
2.3 Error Code FIP
2-70
FIP1.24 092-315 ATC Fail
Step Check and Action Yes No
Parts considered to be the cause
Drum Cartridge [XERO ASSY] (PL8.1.1)
CONNECTOR ASSY XERO (PL5.1.10)
HARNESS ASSY XERO CRUM (PL18.3.12)
PWBA MCU (PL18.2.2)
1
Check the installation of the Drum Cartridge
Is the Drum Cartridge installed properly, with no foreign
substances at the contact point between the ATC Sensor
in the Drum Cartridge and the CONNECTOR ASSY
XERO?
Go to Step 2.
Reinstall the
Drum Cartridge
2
Check the ATC Sensor part of the Drum Cartridge
Is the connection terminal of the ATC Sensor part in the
Drum Cartridge damaged?
Replace the
Drum Car-
tridge
Go to Step 3.
3
Check the CONNECTOR ASSY XERO
Is the connection terminal of the CONNECTOR ASSY
XERO damaged?
Replace the
CONNEC-
TOR ASSY
XERO (REP
5.4)
Go to Step 4.
4
Check connector connection
Check the connection between the CONNECTOR ASSY
XERO and the PWBA MCU.
Is the HARNESS ASSY XERO CRUM (P/J254-P/J25) con-
nected securely?
Go to Step 5.
Securely con-
nect the HAR-
NESS ASSY
XERO CRUM
(P/J254-P/J25)
5
Check after replacing the Drum Cartridge
Replace the Drum Cartridge.
Does an error occur?
Go to Step 6. End of work.
6
Check after replacing the CONNECTOR ASSY XERO
Replace the CONNECTOR ASSY XERO.(REP 5.4)
Does an error occur?
Go to Step 7. End of work.
7
Check after replacing the HARNESS ASSY XERO CRUM
Replace the HARNESS ASSY XERO CRUM.
Does an error occur?
Replace the
PWBA MCU.
(REP 18.2)
End of work.
