Chapter 2 Troubleshooting
2.3 Error Code FIP
2-84
FIP2.11 SOLENOID FEED MSI (PL13.1.5)
Step Check and Action Yes No
Parts considered to be the cause
GEAR SEGMENT MSI 1 (PL13.1.6)
GEAR SEGMENT MSI 2 (PL13.1.7)
SOLENOID FEED MSI (PL13.1.5)
PWBA MCU (PL18.2.2)
1
Check for foreign substances in the SOLENOID FEED MSI
Drive Section
Are there any foreign substances in the SOLENOID FEED
MSI Drive Section?
Remove the
foreign sub-
stances
Go to Step 2.
2
Check the shape of the GEAR SEGMENT MSI 1 and the
GEAR SEGMENT MSI 2
Are the GEAR SEGMENT MSI 1 and the GEAR SEG-
MENT MSI 2 damaged?
Replace the
GEAR SEG-
MENT MSI 1
and the GEAR
SEGMENT
MSI 2
Go to Step 3.
3
Check connector connection
Check the connection between the SOLENOID FEED MSI
and the PWBA MCU.
Is the SOLENOID FEED MSI (P/J15) connected securely?
Go to Step 4.
Securely con-
nect the SOLE-
NOID FEED
MSI (P/J15)
4
Check after replacing the SOLENOID FEED MSI
Replace the SOLENOID FEED MSI.
Does an error occur?
Replace the
PWBA MCU.
(REP 18.2)
End of work.
To Next Page
