Maintenance 261
Replacing the Fusing Unit, Transfer Unit, Retard Roll,
Feed Roll and Nudger Roll
You need to replace five parts (fusing unit, transfer unit, retard roll, feed roll and nudger roll) at a time. The transfer
unit, the retard roll, the feed roll and the nudger roll for replacement come with a new fusing unit.
Fuji Xerox fusing unit, transfer unit, retard roll, feed roll and nudger roll are available only through Fuji Xerox. To
order by phone, see also "Online Services" on page 293.
It is recommended that you use Fuji Xerox fusing unit, transfer unit, retard roll, feed roll and nudger roll for your
printer. Fuji Xerox does not provide warranty coverage for problems caused by using accessories, parts, or
components not supplied by Fuji Xerox.
This section includes:
• "Removing the Fusing Unit" on page 262
• "Installing a Fusing Unit" on page 263
• "Removing the Transfer Unit" on page 263
• "Installing a Transfer Unit" on page 264
• "Removing the Retard Roll in the Standard 550 Sheet Tray" on page 265
• "Installing a Retard Roll in the Standard 550 Sheet Tray" on page 266
• "Removing the Feed Roll and Nudger Roll" on page 267
• "Installing the Feed Roll and Nudger Roll" on page 270
• "Resetting the Counter of the Fusing Unit" on page 271
Overview
When a fusing unit reaches its usable life-span, the following messages appear on the LCD panel.
• Fusing Unit Safety
When removing the Fusing Unit, always switch off first and wait for 40 minutes until it cools off.
Message Remaining Page Yield Printer Status and Action
Fusing Unit Life
Replace Soon
20,000 pages The fusing unit is near the end of its life. Prepare a
new one.
Replace the fusing unit as well as the transfer unit at
the same time.
Fusing Unit Life
Replace
- The fusing unit has reached the end of its life. Replace
the old fusing unit with a new one.
To Next Page
