Network Settings
223
System Settings
11
The following items can be set with [Port Settings].
[System Settings]>[System Settings]>[Network Settings]
Protocol Settings
This screen allows you to configure the settings
required for communication.
The following items can be set with [Protocol Settings].
Ethernet Setting
Select the Ethernet communication speed from the following items.
Items Notes
HTTP
Select [Enabled] when using CentreWare Internet Services.
See • For details of CentreWare Internet Services, refer to
CentreWare Internet Services Help.
LPD
Select [Enabled] when outputting via LPR.
FTP
Select [Enabled] when connecting via FTP.
SNMP
Select [Enabled] when using our remote administration soft-
ware, etc. via SNMP.
Items Notes
Auto
Select this item to automatically detect the Ethernet communi-
cation speed.
1000 Mbps Full-Duplex
Select this item to fix the speed to 1000 Mbps Full-Duplex.
100 Mbps Full-Duplex
Select this item to fix the speed to 100 Mbps Full-Duplex.
100 Mbps Half-Duplex
Select this item to fix the speed to 100 Mbps Half-Duplex.
10 Mbps Full-Duplex
Select this item to fix the speed to 10 Mbps Full-Duplex.
10 Mbps Half-Duplex
Select this item to fix the speed to 10 Mbps Half-Duplex.
Protocol Settings
1.Ethernet Setting
2.TCP/IP-IP Address
3.TCP/IP-Subnet Mask
4.TCP/IP-Gateway Address
Auto
192.168.1.1
255.255.255.0
192.168.1.1
Close
Items Current Settings
To Next Page
