Step 2
Unlatch the ber restraint gates on each side of the blade.
Note: Slide the ber restraint gate slightly inward to open the gate.
Fiber Restraint
Gate
Open
Closed
PIU Slots
Set Screw
FNC000054_Rev_01
Figure 70
Unlatching Fiber Restraint Gate
Step 3
Aer opening the ber restraint gates, secure the blade to the 1FINITY Housing using the set screws on the le-
and right-hand sides of the blade.
Note: The set screws for securing the blade are accessible aer opening the ber restraint gates on the le-
and right-hand sides of the blade.
Step 4
Perform the same procedure for each blade to be installed.
Warning:
Aer the blade is seated in the housing, it should not be removed, reseated, or power down for
at least 15 minutes. Repeve restart of the blade within 15 minutes causes database corrupon, which
leads to blade start-up failure and requires a return to factory for reprogramming.
✓ This task is complete.
Equipment Installation
Install Blade in Housing
138
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
