Congure LCN1 with DHCP
Prerequisites:
■ If port LCN1 requires a pluggable SFP module, the SFP is installed and its autoprovisioning is complete.
■ A DHCP server is operang on the LAN.
Overview
At the site where the NE is installed, the LAN connects to a router and the DCN is reachable through the router. A
DHCP server is operang on the LAN. LCN1 is congured with DHCP enabled by factory default. With this
conguraon, the DHCP server automacally assigns an IP address to LCN1 when it is connected to the LAN. To
establish IP communicaon beyond the LAN, the user must congure the next-hop IP address on the NE roung
instance.
This secon describes the procedure to congure the default next-hop IP address, and install a LAN cable
connecng LCN1 to the LAN. The LAN cable can connect directly to a LAN switch port as shown in the following
gure.
Virtuora User
Interface
WebGUI
CLI
NETCONF/
YANG
Router
Next-hop IP address
Virtuora NC
DCN
Switch
Remote Users
NE Installation Site
1FINITY NE
LCN1
LAN cable
DHCP Server
LAN
Figure 89
LAN Switch Port Connecon
The following gure shows how to save LAN switch ports by connecng the LAN cable to a daisy chain of LAN
cable connecons between 1FINITY NEs.
Initial System Turn Up
Congure IP Connection to DCN
173
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
