Table 33 (Cont.)
4-Degree Small ROADM Cabling Add/Drop Connecons
From To
Degree L100 Port L110 Blade Slot Port
3 C7 2 1 E3
3 C6 2 2 E3
3 C5 3 1 E3
3 C4 3 2 E3
4 C9 1 1 E4
4 C8 1 2 E4
4 C7 2 1 E4
4 C6 2 2 E4
4 C5 3 1 E4
4 C4 3 2 E4
Unit Description
CD ROADM Cabling
91
Release 19.1.1 · Issue 1.1, May 2021
