Functional checks
Vivid E80/E90/E95 – Service Manual 4-33
GC091052 Rev. 3
Operating Panel Test
• The Operating Panel is tested when the Vivid E80/E90/E95
is powered up as part of the start-up scripts, run at every
start-up.
Related information:
• ‘Troubleshooting’ on page 7-8
Peripheral checks
Printer checks
The internal printer is controlled from the P1 and P2 keys on the
Vivid E80/E90/E95’s Operating Panel.
The factory default is:
• P1 for the internal printer
• P2 for external (network) printer
Table 4-3: Printer checks
Step Task Expected Result(s)
1.
When scanning in 2D Color Mode,
Press Freeze to stop image
acquisition.
Image scanning stops with the last
picture on the screen.
2.
Press P1 on the Operating Panel The image displayed on the screen
is printed on the assigned printer.
3.
Press P2 on the Operating Panel The image displayed on the screen
is printed on the assigned printer.
4.
Check if the print quality on the
pictures from both printers are of
expected quality.
