Replacement Procedures
8-54 Vivid E80/E90/E95 – Service Manual
GC091052
Rev. 3
1. Disconnect the cables from the Bulkhead Board:
• cable from Main Cable
• cables to left and right speaker
• two short USB cables (Bulkhead Board to OP)
2. Unscrew and remove two screws.
3. Remove the Bulkhead Board.
Install the Bulkhead Board
Follow this procedure to install the Bulkhead Board:
1. Slide the Bulkhead Board into the correct position.
2. Install the two screws (M3 x 6, Torque: 1.2 Nm).
3. Install the cables from the Bulkhead Board:
• two short USB cables (Bulkhead Board to OP)
• cables to left and right speaker
• cable from Main Cable
4. Install the Upper OP panel and the rotary knobs.
5. Connect probe(s) and external cables (network and mains
power).
Bulkhead, Plate, Extended replacement
Read and follow
WARNING
Energy Control and Power Lockout for .
When servicing parts of the Ultrasound system where there is
exposure to voltage greater than 30 volts:
1. Follow LOCK OUT/TAG OUT procedures.
2. Turn off the breaker.
3. Unplug the Ultrasound system.
4. Maintain control of the Ultrasound system power plug.
5. Wait for at least 30 seconds for capacitors to discharge as
there are no test points to verify isolation.
Ultrasound System components may be energized.
