Replacement Procedures
8-70 Vivid E80/E90/E95 – Service Manual
GC091052
Rev. 3
Install the Fan Assembly
Follow this procedure to install the Fan Assembly:
1. Align the Fan Assembly with the rails in the frame and push
it into position.
2. Install the Card Rack Cover.
3. Install the screws of the Card Rack Cover.
4. Install the Right Side Cover.
Main Cable replacement
Read and follow
Preparations
When preparing for the replacement, you must perform the
following steps:
Energy Control and Power Lockout for Vivid E80/E90/E95.
When servicing parts of the Ultrasound system where there is
exposure to voltage greater than 30 volts:
1. Follow LOCK OUT/TAG OUT procedures.
2. Turn off the breaker.
3. Unplug the Ultrasound system.
4. Maintain control of the Ultrasound system power plug.
5. Wait at least 30 seconds for capacitors to discharge as
there are no test points to verify isolation.
Ultrasound System components may be energized.
DO NOT touch any boards with integrated circuits prior to
taking the necessary ESD precautions.
Always connect yourself, via an arm-wrist strap, to the advised
ESD connection point located on the rear of the Ultrasound
system (near the power connector).
Follow general guidelines for handling of electrostatic sensitive
equipment.
