Replacement Procedures
8-36 Vivid E80/E90/E95 – Service Manual
GC091052
Rev. 3
3. Disconnect all probes and external I/O cabling.
4. Remove the OP Panel Knobs, including the Volume control
knob.
Remove the Upper OP Panel/Touch Panel Assembly
NOTE: For better access, swing the LCD Monitor to the side.
Follow these steps to remove the Upper OP Panel/Touch Panel
assembly. Ensure that the OP Panel is in its uppermost position
with the LCD out of the way:
1. At the rear of the Ultrasound system, release the
XY mechanism by inserting a screwdriver into the release
point and pressing until release.
2. Pull the Top Console out to its extended position to gain
access to the screws in the next step.
3. Remove four screws with washers from the Operating
Panel’s back cover.
4. Lift the Upper OP Panel/Touch Panel assembly slightly from
the bottom, and then tilt the top toward the front of the
Ultrasound system. There are tabs at the bottom of the
Touch Panel Assembly. Pull straight up on these tabs.
5. Disconnect the cables at the back of the Upper OP Panel/
Touch Panel Assembly.
6. Lift out the Touch Screen Assembly and place it on a clean
and ESD safe surface.
Install the Upper OP Panel/Touch Panel Assembly
Follow these steps to install the Upper OP Panel/Touch Panel
Assembly:
1. Place the Upper OP Panel/Touch Panel Assembly in the
frame.
2. Ensure that all Ground cables are connected
3. Connect the cables you disconnected earlier to the
Operating Panel, Upper.
4. Install the Upper OP Panel/Touch Panel Assembly.
5. Install the four screws to the Back Cover from behind.
CAUTION
Failure to remove the OP Panel Knobs first could cause
damage to the knob shafts.
