System Setup
3-18 Vivid E80/E90/E95 – Service Manual
GC091052
Rev. 3
Completing the setup
System specifications
System requirements verification
• Verify that the site meets the requirements listed in
Chapter 2.
(See: ‘Facility needs’ on page 2-10.)
• Verify that the specifications below do not conflict with any
on-site conditions.
Physical dimensions
Mass with monitor and peripherals
Table 3-7: Physical dimensions of Vivid E80/E90/E95 with
monitor and peripherals - in transportation position
Height Width Depth Unit
141.0 58.5 83.0 cm
55.5 23 32.7 Inches
Table 3-8: Mass of Vivid E80/E90/E95 with monitor, without
probes and peripherals
Model Mass [KG] Mass [LBS]
Vivid E80/E90/
E95
128 283
