Top Console parts
Vivid E80/E90/E95
–
Service Manual
9-9
GC091052
Rev. 3
T
op Console p
arts
Main Monitor and LCD A
rm p
art
s
T
able
9-4:
Main Monitor
- Eizo-19 inch, wide
ITEM
PA
R
T
NUMBER
DESCRIPTION
QTY
CRU
FRU
1.
S5444781
LCD only 19 inch FRU
1
N
Y
2.
S5438354
Cover-Monitor_Rear FRU
1
N
Y
3.
5447216-2
Monitor Serv
ice Cover-White
1
N
Y
4.
S5490514
Cover-Monitor Front FRU
1
N
Y
5.
5490514-3
MONITOR FRONT COVER
ASSY - Anthracite metallic
1N
Y
