17 - Automatic Tuning Parameters
Code Parameter Name / Range
17-00 Mode selection of automatic tuning
0: Rotational auto-tuning
1: Static auto-tuning
2: Stator resistance measurement
3: Reserved
4: Loop tuning
5: Rotational Auto-tuning Combination (Item: 4+2+0)
6: Static Auto-tuning Combination (Item: 4+2+1)
17-01 Motor rated output power
0.00~600.00 kW
17-02 Motor rated current
For VF, VF+PG modes, 10%~200% of the inverter rated current
For SLV, SV modes, 25%~200% of the inverter rated current.
17-03 Motor rated voltage
230V:50.0~240.0 V
400V:100.0~480.0 V
17-04 Motor rated frequency
5.0~599.0 Hz
17-05 Motor rated speed
0~24000 rpm
17-06 Pole number of motor
2~16 pole
17-07 Number of PG pulse
0~60000 PPR
17-08 Motor no-load voltage
230V: 50~240V
400V: 100~480 V
17-09 Motor excitation current
15~70% motor rated current
17-10 Automatic tuning start
0: Disable
1: Enable
17-11 Error history of automatic tuning
0: No error
1: Motor data error
2: Stator resistance tuning error
3: Leakage induction tuning error
4: Rotor resistance tuning error
5: Mutual induction tuning error
6: Encoder error
7: DT Error
8: Motor’s acceleration error
9: Warning
Notes:
- Values are for 230V class, double the values for 400V class.
- In HD mode (00-27=0) the range is 0.0 to 400.0 Hz, 0.0 to 120.0Hz in for ND mode (00-27=1) and 0.0 to
599.0Hz is high frequency mode.
Auto-tuning
Based on the motor nameplate set the motor rated output power (17-01), motor output rated current (17-02),
motor rated voltage (17-03), motor rated frequency (17-04), motor rated speed (17-05) and number of motor
poles (17-06) to perform an auto-tune.
VDI100 • Instruction manual 253
