gefran VDI100 Series User Manual

4.5.2. Basic Command Function
●D(d)commandfunction
Example1:I1─D───[Q1
I1
D
Q1
OFF
OFF
OFF
ON
ON
ON
OFF
OFF
OFF
New scanning cycle
Example2:i1─d───[Q1
I1'
i1
d1
OFF
OFF
ON
ON
OFF
OFF
New scanning cycle
ON
OFF
ON
Q1
OFF
ON
OFF
I1' is the inverse logic of i1
●NORMAL(-[)output
I1───[Q1
I1
OFF
ON
OFF
Q1
OFF
ON
OFF
●SET(▲)output
I1───▲Q1
I1
OFF
ON
OFF
Q1
OFF
ON
● RESET(▼)output
I1─── ▼ Q1
I1
OFF
ON
OFF
Q1
OFF
ON
● P output
i1───PQ1
I1'
i1
Q1
OFF
ON
OFF
ON
OFF
ON
ON
ONOFF OFF OFF
I1' is the inverse logic of i1
VDI100 • Instruction manual 287
