gefran VDI100 Series User Manual

11.7. Other Options
A. Blank cover and keypad extension cable
When used for remote control purposes, the keypad can be removed and remotely connected with an exten-
sion cable. Extension cables are available in the following lengths: 1m (3.3ft), 2m (6.6ft), 3m (10ft), and 5m
(16.4ft).
Remotecontrol
Name Model Specification
LED digital operator wire
with blank cover
KB cable 1m 1m (3.3ft)
KB cable 2m 2m (6.6ft)
KB cable 3m 3m (10ft)
KB cable 5m 5m (16.4ft)
When using a remote mount keypad a blank cover can be installed in place of the original keypad to prevent
dust and debris from entering the inverter.
Blankkeypadcover
Name Model Specification
Blank cover
KB-BLI-VDI100 Blank cover
KB-LED-VDI100keypaddimensions
348 VDI100 • Instruction manual
