Register No. Bit Content
2522H
DI State
0 Terminal S1
1 Terminal S2
2 Terminal S3
3 Terminal S4
4 Terminal S5
5 Terminal S6
6 Terminal S7
7 Terminal S8
8 Reserved
9 Reserved
A Reserved
B Reserved
C Reserved
D Reserved
E Reserved
F Reserved
2523H Frequency command (0.01Hz)
2524H Output frequency (0.01Hz)
2525H Reserved
2526H DC voltage command (0.1V)
2527H Output current (0.1A)
2528H
Warning Description
0 No alarm 20 EF4 40 EF 60 Reserved
1 OV 21 EF5 41 Reserved 61 RETRY
2 UV 22 EF6 42 Reserved 62 SE07
3 OL2 23 EF7 43 RDP 63 SE08
4 OH2 24 EF8 44 Reserved 64 Reserved
5 Reserved 25 Reserved 45 OL1 65 OH1
6 OT 26 CLB 46 HP_ER 66 FIRE
7 Reserved 27 Reserved 47 SE10 67 ES
8 Reserved 28 CT 48 Reserved 68 STP1
9 UT 29 USP 49 BB1 69 BDERR
10 OS 30 RDE 50 BB2 70 EPERR
11 PGO 31 WRE 51 BB3 71 ADCER
12 DEV 32 FB 52 BB4 72 Reserved
13 CE 33 VRYE 53 BB5 73 STP0
14 CALL 34 SE01 54 BB6 74 ENC
15 Reserved 35 SE02 55 BB7 75 STP2
16 EF0 36 SE03 56 BB8
17 EF1 37 Reserved 57 Reserved
18 EF2 38 SE05 58 Reserved
19 EF3 39 HPERR 59 Reserved
2529H Digital Output State
252AH AO1 (0.00V ~ 10.00V)
252BH
AO2 (0 ~ 1000): Voltage (corresponding to
0.00~10.00V); Current (corresponding to 4mA~-
20mA)
252CH Analog Input 1 (0.1%)
252DH Analog Input 2 (0.1%)
252EH Reserved
252FH VDI100/BDI50 Check
Note: Write in zero for Not used BIT, do not write in data for the reserved register.
* If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz
298 VDI100 • Instruction manual
