else {
wkg = wkg >> 1;
}
}
}
return( wkg );
}
Error code
ASCII Mode RTU Mode
STX ‘:’ Node Address 02H
Address
‘0’ Function 83H
‘1’ Exception code 52H
Function
‘8’
CRC-16
High C0H
‘6’ Low CDH
Exception code
‘5’
‘1’
LRC Check
‘2’
‘8’
END
‘CR’
‘LF’
During a communication error the drive will response with an Exception Code and send a message back to the
main system consisting of a Function Code that is “ANDED (and 80h)” with 80 Hex.
Exception code Content
01 Function code error
02 Register number error
03 DATA setting error
04 Register number is over 32
4.6.2. Register and Data Format
CommandData(Read/Write)
Register No. Bit Content
2501H
Reserved
Operation Signal
0 Operation Command 1 : Run 0 : Stop
1 Reverse Command 1 : Reverse 0 : Forward
2 External Fault 1 : Fault
3 Fault Reset 1 : Reset
4 Reserved
5 Reserved
6 Multi-function Comm S1 1 :“ON”
7 Multi-function Comm S2 1 :“ON”
8 Multi-function Comm S3 1 :“ON”
9 Multi-function Comm S4 1 :“ON”
A Multi-function Comm S5 1 :“ON”
B Multi-function Comm S6 1 :“ON”
C Multi-function Comm S7 1 :“ON”
D Multi-function Comm S8 1 :“ON”
E Inverter mode 1 : “ON”
F Torque Command set by Communication 1: “ON”
2502H *Frequency Command (Unit: 0.01Hz)
2503H Torque Command (+/-8192 corresponding to the rated torque +/-100%)
2504H Speed limit (+/- 120 corresponding +/-120%)
2505H AO1 (0.00V ~ 10.00V)
2506H
AO2 (0 ~ 1000): Voltage (corresponding to 0.00~10.00V); Current
( corresponding to 4mA~20mA)
2507H DO
2508H Reserved
2509H Reserved
250AH Reserved
296 VDI100 • Instruction manual
